factory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machine
Technical Parameter

light keel and stud sheet steel drywall profile forming machine light steel keel roll forming machine

Automatic Omega Channel Profile Truss Furring Cold Roll Forming Machine With Servo Motor Steel Frame

light keel and stud sheet steel drywall profile forming machine light steel keel roll forming machine

Automatic Omega Channel Profile Truss Furring Cold Roll Forming Machine With Servo Motor Steel Frame

factory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machine



factory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machine





Coil Material

Type

Galvanized Steel Sheet

Thick

0.4-0.6mm

Uncoiler (manual/automatic)

Weight Capacity

3T

Inner Diameter

460-520mm

Outside Diameter

1400mm

Coil width

Max 600mm

Feeding and

Pinch rollers

one pair, up and down

straightening device

Straightening rollers

up three, down four

Diameter of rollers

75mm

Roll Former

Frame type

single station

Forming Roller stand

about 14 Groups

Shaft material

High grade 45# steel,

Heated and quenched HRC55-60°

Shaft diameter

50mm

Roller material

GCr15

Drive Type

By gear

Forming Speed

40-45m/Min

Motor

5.5KW reducer with

requency control

Cutting

Type

After-cutting, hydraulic

Hydraulic cutter

Material of mould

Cr12

With quenching treatment55-60°

Cutting tolerance

10M+/- 2.0 mm

Feature

no distort, no wasting , high safe
factor.(main motor stop cutting)

PLC cabinet

PLC

XINJIE

Length Controller

Encoder

Operation

Touch Screen

Transducer

Delta

Hydraulic station

Hydraulic station power

4 KW*2

Hydraulic pressure

15 Mpa

Runout Table

Non-power type

2 pcs



factory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machinefactory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machinefactory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machinefactory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machine





factory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machine



factory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machine



factory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machine



factory price u c track stud metal ceiling light steel roof gutter profile roll keel forming machine

Q: How to maintain the machine?
A: add mechanical lubrication equipment to chain, bearing and cutting slide every month. Add mechanical lubrication to the case every half a year.
Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.
Q:How many workers to operate the machine?
A:Only 1-2 workers.
Q: How to visit your company?
A:a.Fly to Beijing airport: By high speed train From Beijing Nan Station to Cangzhou West Station(1 hour), then we can pick you up .
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou West station(4.5 hours), then we can pick you up.
Q: What can you do if the machine broken?
A:Our machine’s warranty period is 12months,if the broken parts can’t be repaired,we can send the new parts to replace the broken parts for free,but you need pay the express cost yourself.if over warranty period,we can for to solve the problems via negotiation,and we supply the technical support for the whole life of the equipment.
Q:How can I trust you that machines pasted testing running before shipping?
A: 1) We record the testing video for your reference. Or,
2) Please visit company and test machine if convenient.
