Standing Seam Roof Roll Forming Machine
Technical Parameter

With feeding material guide, body frame made from H450 type steel by welding
Side wall thickness: Q235 t18mm
Rollers manufactured from 45# steel, high-frequency heat treatment
The material for Embossing roller: bearing steel GCr15 for long working life, heat treatment
Shafts Diameter=100mm, precision machined
Motor Driving, Gear /Sprocket driving transmission, about 23-steps to form
Main Motor=15KWx2, Frequency speed control
Speed reducer motor: R series;
All the screw bolts with grade 8.8(cheap factories use low grade 4.8) to ensure fix the machine structure tightly and long life during the machine long time running.
Real forming speed 12-15m/min


JCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming Machine

JCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming MachineJCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming Machine

Main Machine
With feeding material guide, body frame made from H450 type steel by welding
Side wall thickness: Q235 t18mm
Rollers manufactured from 45# steel, high-frequency heat treatment
The material for Embossing roller: bearing steel GCr15 for long working life, heat treatment
Shafts Diameter=100mm, precision machined
Motor Driving, Gear /Sprocket driving transmission, about 23-steps to form
Main Motor=15KWx2, Frequency speed control
Speed reducer motor: R series;
All the screw bolts with grade 8.8(cheap factories use low grade 4.8) to ensure fix the machine structure tightly and long life during the machine long time running.
Real forming speed 12-15m/min



 Post Hydraulic Cutting Device

Post to cut, stop to cutting,Three pieces type of cutting blade design, no blanking
Hydraulic motor:7.5 KW ;
Cutting tool material: Cr12MoV
The cutting power is provided by the main engine hydraulic station



PLC Control System
Control The Quantity And Cutting Length Automatically
Input The Production Data(Production Batch,pcs,Length,etc.)On The Touch Screen ,It Can Finish The Production Automatically.JCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming Machine



Main Parameters

Item

Name

Description

1

Decoiler

Capacity:5 tons

2

Material

Steel Coil

3

Thickness

0.5-1.2mm

4

Transmission

Chain/Gear/Gearbox

5

Speed

10-15m/min

 6

Roller

Steel with quenched treatment,chromed on the surface

7

Shaft

steel with tempering treatment

8

Cutting type

Hydraulic cutting

9

Cutting material

Cr12 with quenched treatment Hardness58°-62°

10

Welding

Automatic spot welding

11

Control system

PLC

12

Electric brand

Delta,Siemens,Schneider

13

Voltage

380V,50HZ,3PH(or as customers’ request)



JCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming Machine



Sr. No.

Component

Quantity

01

Decoiler 3 Ton

1 Set

02

Pitch Roll,Leveler and Feeder

 1 Set

03

Roll Forming Main Machine

 1 Set

04

Hydraulic Auto Punching Holes

 1 Set

05

Hydraulic Auto Cutting

1 Set

06

Hydraulic Power Bank

1 Set

07

Elc. Control Panel (PLC Base)

1 Set



JCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming Machine

Main Features
1.The roll forming machine can rollform metal roofing sheet. After roll formed by this roll forming machine, the surface will be very smooth and beautiful without any scratch on surface.
2.Rollforming process:uncoiler, straightening,rollforming, cut to length,Runout table.
3.Fully Automatic Control System with PLC.
4.Easy operation: Key in the length and quantity on the control panel.
5.One year warranty.
6.we also can do a custom roll forming machine, We can design the machine according to your specification and profile drawing.
7.One roll forming machine can produce one or two profiles.

JCH Mechanically Locked Standing Seam Metal Roofing Panel Roll Forming Machine

Sr. No

Optional Component

Quantity

01

Hydraulic Coil Decoiler

1Set

02

Coil Car

1Set

03

Auto Stacker 20 Ft. Length

1Set

04

Electrical Coil Decoiler

1Set

05

Telescopic Type Machine Guard

1Set
